Design For Testability (DFT)

Our team of Design for Testability experts can help increase IC test coverage, yields and quality.

Design For Testability Overview


Continuously shrinking process nodes have introduced new and complex on-chip variation effects creating new yield challenges. Combined with ever-increasing design complexity with multiple memories, mixed signal blocks and IPs from multiple vendors crammed into a single SoC, Design for Test (DFT) implementation and Production Test signoff has become a major challenge. The Tessolve asureDFT services suite helps you to overcome these challenges by establishing a DFT strategy that delivers improved DFT execution quality and reduced time-to market.

AsureDFT Web



Implementing Scan ( Compression/ non-compression ) implementation with industry standard tools


ATPG (stuck-at, at-speed, SDD, Path delay, new faults based on the technology and strategy) vector generation, Covergae analysis, Pattern (verilog, wgl) simulation (Gate Level Simulations (unit-delay, extracted dealy with sdf)


Memory BIST implementation, Simulation & Vector preparation for good simulation and repair flow with fault Injections with industry standard EDA tools

  • Experienced professionals can support on the in-house tool based implementation/verification for our customers.
  • Logic BIST
  • IEEE 1149.1, IEEE1149.6 compliance test controllers (JTAG)
  • Ensuring the design integrity on pre and post DFT by Formal Verification
  • ATE support on pattern stabilization, split lot analysis / Diagnosis of Structural (scan, mbist) failures

Off-the-Shelf DFT Components

  • JTAG TAP based test controllers and verification frame works (JTAG, IEEE 1149, TAP and its customized Instructions)
  • Test suites for Verifying BSCAN and generating tests for DC parametric tests (No dependencies with EDA Tool)
  • Generating Tester compatible vectors for Post Si validation (ATE)
  • Format conversions with ATE logs for diagnosis

Design for Testability Training

  • DFT Strategy/Structural Testing with testmode STA needs
  • Exclusive trainings on JTAG, BSCAN, SCAN, MBIST
  • Customized contents for customer requirements

Design for Testability Methodology Services

  • Development of DFT methodology
  • Assessment of existing DFT methodology

Benefits of Design for Testability

  • Reduced overhead due to trained skills being available – No need to hire expensive DFT resources
  • End-to-end support – From design to silicon
  • Off the shelf components – Reduce DFT turnaround times
  • Training support – Bridge the gap in experience levels; Remote support from Tessolve office to resources at customer sites

Benefits of Design for Testability


End-to-end DFT for a consumer SoC

Tessolve was tasked with scan implementation, verification and pattern delivery for a complex consumer SoC which had a flop count of around 1.5 million. Memory BIST (MBIST) also had to be performed for 400+ memory instances. The stuck at and at-speed coverage analysis targets were set at 99% and 85% respectively.


Implementing DFT for a network SoC

When a customer urgently needed a team of engineers for DFT implementation and execution of its network SoC, they turned to tessolve for help. After the design had been analyzed and the DFT implementation effort had been estimated, Tessolve had to execute DFT DRC for Scan and implement compression and the stuck-at coverage target for the SoC was an aggressive 99.8%
